At sea level the atmosphere pushes on every surface at roughly 101 kPa, or about 14.7 psi. A vacuum cup removes air from the sealed pocket between the cup lip and the workpiece. The pressure difference between the atmosphere and the evacuated pocket is what clamps the part down. There is no magnet, no screw and no hydraulic ram doing the work.

The force is simple to estimate. Multiply the pressure difference by the sealed area. A cup with a 100 mm × 100 mm sealed footprint gives 10,000 mm². At a partial vacuum of 0.8 bar, that is about 800 N, or roughly 80 kgf. Spread over that area, the load is gentle enough that thin aluminium plate will not dimple.

That last point is the reason vacuum exists as a workholding method. Vises and clamps concentrate force at a few contact points. Vacuum distributes it. For a 2 mm sheet, a 6061 plate or a carbon fibre panel, a point load is what bends the part and ruins the flatness you are trying to machine.

The trade is stiffness. A vacuum cup resists pull-off well and side load poorly. Cutting forces in X and Y must be handled by friction or by mechanical stops. This is the first thing to check before you trust a vacuum setup on a heavy cut.

• 1
  Force = pressure × sealed areaEstimate the hold before you design the fixture, not after.
• 2
  Distributed, not concentratedGood for thin or polished parts that a clamp would mark.
• 3
  Weak against side loadFriction coefficient between cup and part sets the limit.

The seal is the part that fails. A cup only holds while the lip maintains contact with the workpiece. Any path for air to leak back into the pocket reduces the pressure difference and the holding force drops with it. A small leak does not fail gradually, it fails suddenly once the pump cannot keep up.

Machined surfaces seal better than cast or as-machined surfaces. A face-milled 6061 surface at Ra 1.6–3.2 μm seats against a nitrile or silicone gasket with little leakage. A sand-cast surface with draft angles and parting lines needs a softer, thicker gasket, and even then the seal is marginal. If the part has a rough or porous face, plan for a compliant seal or a different workholding method.

Seal material matters as much as seal shape. Nitrile is the default for dry aluminium and steel. Silicone handles higher temperatures but tears more easily on burrs. For stainless and titanium, chloroprene or EPDM resists the coolant and chip load better. Deburr the part edge before it touches the gasket. A 0.2 mm burr slice is enough to open a leak path.

Multiple small cups beat one large cup when the part is not flat. Each cup seals independently, so a low spot in the middle does not drain the whole system. This is how vacuum tables handle slightly bowed plate without shimming.

• 1
  Leak path = lost forceOne open lip can drop holding force below the cutting load.
• 2
  Match gasket to surface finishSoft gasket for cast or rough faces, hard for machined faces.
• 3
  Deburr before loadingSharp edges cut the lip and create a permanent leak.
• 4
  Independent cups for uneven partsOne low spot should not unseal the whole fixture.

Two numbers describe a vacuum system: the flow rate of the pump and the deepest vacuum it can reach. Flow rate covers leakage. Deep vacuum covers holding force. A large vacuum pump with poor sealing will still lose the part, and a small pump on a tight seal can hold a heavy plate.

For most CNC vacuum cup safety workholding, a vacuum of 20–25 inHg is enough. That is roughly 0.68–0.85 bar of pressure difference. Going deeper adds force but also pulls the part harder into the gasket, which can deform thin sheet. Venturi vacuum generators reach this range with shop air, but they consume a lot of compressed air and are noisy. Rotary vane or dry claw pumps are quieter and cheaper to run for long cycles.

Add a vacuum reservoir and a check valve between the pump and the fixture. If the pump stops, the reservoir buys time and the check valve stops the flow reversing. A pressure switch with an alarm should be wired to the machine control. If vacuum drops below the set point, the cycle stops. This is not optional on a spindle running at 12,000 rpm.

Watch the pressure gauge during the first cuts. A stable reading means the seal is holding. A slow drift downward means a leak that will get worse as chips work under the lip. Chip clearance around the seal is a design requirement, not a cleaning habit.

• 1
  20–25 inHg is the working rangeEnough force for most plate and frame work.
• 2
  Reservoir plus check valveBuys time if the pump stops mid-cut.
• 3
  Alarm interlocked to the controlStop the spindle when vacuum falls below set point.
• 4
  Keep chips away from the lipA chip under the gasket is a slow leak.

Vacuum workholding is a poor fit for parts with small flat area, deep pockets that break the seal, or heavy interrupted cuts. A part with a 30 mm × 30 mm sealing face gives only 900 mm². At 0.8 bar that is 72 N. A roughing end mill in 4140 steel will exceed that in a single pass.

It is also wrong for parts that need to be machined on all six faces in one setup. Vacuum holds one face, so the opposite face is free. Five-axis work on a vacuum fixture is possible, but the part must be light enough and the cuts light enough that the friction budget covers the tangential load. When in doubt, use a mechanical fixture for the first operation and vacuum only for the finishing pass.

Porous materials are a problem. Some castings and sintered parts leak air through the material itself. The pump pulls vacuum through the part and never reaches the set point. Seal the back face with tape or a coating, or switch to a mechanical clamp.

Vacuum is at its best on flat plate, sheet, thin wall frames and parts where surface finish must be preserved. It is at its worst where the part is small, tall or interrupted. Match the method to the geometry instead of forcing vacuum onto every job.

• 1
  Small sealing area, small forceBelow about 2,000 mm², check the numbers carefully.
• 2
  Porous material will not holdAir passes through the part, not just around it.
• 3
  One face onlyThe opposite side is unsupported for the next operation.

Confirm the material and the face finish. A 6061-T6 plate face-milled to Ra 0.8–1.6 μm seals well with a nitrile gasket. A 304 stainless blank with a saw-cut face does not. If the face is rough, take a light facing pass first or use a soft gasket. This single step prevents most vacuum failures we see.

Check the friction budget. The side load a cup can resist equals the holding force multiplied by the friction coefficient. Nitrile on dry aluminium is around 0.5. With coolant in the interface it drops to 0.1 or less. That is a five-fold reduction in side load capacity. If the cut runs wet, add mechanical stops or reduce the radial depth of cut.

Calculate the tangential force from your cut. A 20 mm end mill at 2 mm radial depth in aluminium can produce several hundred newtons of tangential force. Compare that to the friction budget, not to the holding force. Engineers who compare against holding force alone overestimate the setup by a wide margin.

Log the vacuum reading at the start of every cycle. A trend of slowly falling vacuum across a batch tells you the gasket is wearing or chips are accumulating. Replace the gasket on schedule rather than on failure. On our own 5-axis and 3-axis machines we treat the vacuum gauge as a process parameter, not a background indicator.

• 1
  Face finish firstA light facing pass makes the seal predictable.
• 2
  Friction, not holding forceCoolant can cut side load capacity by 5×.
• 3
  Track vacuum across batchesA slow downward trend predicts gasket failure.
