Turning is the right process when the part is mostly round and the critical features rotate around one axis. Shafts, bushings, fittings, valve bodies, connectors, threaded inserts, sensor housings: if you can describe the part as a diameter plus a length, turning will usually beat milling on cost per piece. The tool is stationary, the work spins, and the cycle time scales with the diameter you cut, not with the number of faces.

The economics change once you add off-axis features. A cross-drilled hole, a milled flat, a slot on the side, a hex: each one needs either a second setup or a live tool. A mill-turn center removes the second setup, which matters most on parts under 80 mm where re-chucking error can eat half your tolerance budget. For a part with three cross holes and a flat, mill-turn is often cheaper than turning plus milling, even at a higher hourly rate.

Part size sets the practical ceiling. Our largest turning travel is 4,000 × 400 × 150 mm, and the rotary table is Ø400 mm. Above roughly 400 mm diameter, swing and bar capacity start to limit what a single machine can do, and you should expect the shop to tell you which machine the job will run on. If nobody can name the machine, the quote is a guess.

Volume does not change the process, it changes the setup. Quantities from one piece to 10,000+ pieces run on the same lathes; what changes is whether the shop invests in soft jaws, form tools and a dedicated fixture. Ask what changes between the prototype and the production run. A good answer names a fixture and a gauge. A vague answer means the second run will be re-programmed from scratch.

• 1
  Good fitRound parts, one dominant axis, diameters up to Ø400 mm
• 2
  Better on mill-turnCross holes, flats or slots that would need a second chucking
• 3
  Reconsider the processThin walls under 1 mm, or features on five unrelated faces

A tolerance number on its own means very little. ±0.005 mm on a 6 mm diameter over 10 mm length is a routine turning job. The same number on a 300 mm shaft is a different problem, because thermal drift, chuck pressure and tool wear all scale with length. When a supplier quotes a single tolerance for the whole print, ask which feature it applies to and how it is measured. The answer tells you whether they read the drawing.

Surface finish follows the same logic. Ra 1.6–3.2 μm is a normal turned finish and comes off the tool. Ra 0.8–1.6 μm usually needs a controlled feed rate and a sharp insert. Ra 0.2–0.8 μm generally means a second operation: fine turning, burnishing or grinding. That step adds a setup, a queue and a handling risk. If your print calls for Ra 0.4 μm on one seal diameter and nothing else, say so. Shops that finish the whole part to that level charge you for it.

Material choice moves the achievable numbers more than most buyers expect. Aluminium 6061 and 2024 cut clean and hold ±0.005 mm without drama. Stainless 316 and 17-4PH work-harden, so light passes and rigid setups matter. Titanium TC4 (Ti-6Al-4V) and Inconel push tool wear hard enough that the shop may run two tools per feature to hold size. Copper C110 and brass C36000 machine well but move with heat, so a hot part measured cold will read out of tolerance.

Deburring is where turned parts quietly fail inspection. A sharp edge on a threaded end or a cross hole is a handling injury and a fit problem. Specify the edge condition on the drawing: chamfer size, break radius, or "edges free of burrs". If the drawing is silent, you get whatever the operator decides, and that changes between runs.

• 1
  Routine±0.005 mm on short, rigid, round features
• 2
  Needs a planLong slender shafts, thin walls, deep bores
• 3
  Adds an operationRa 0.2–0.8 μm, tight concentricity, mirror bores

Lead time is three separate numbers. The first is quoting: how long until you get a price and a manufacturability review. The second is material: whether the shop has the bar stock or has to order it. The third is machining and inspection. A supplier that quotes one number for all three is hiding something. We quote and return a free DFM analysis within 12 hours, can start production within 24 hours, and ship parts in 3–5 days for jobs where material is in stock. Those are our numbers; ask every supplier for theirs, broken out the same way.

MOQ is a policy, not a technical limit. Turning a single part is entirely possible; the question is whether the shop will quote it without a punitive setup charge. A supplier with no minimum order quantity has to be organized enough to run a one-off and a 10,000-piece order on the same floor without mixing them up. Ask how the small job is scheduled against the big one. If the answer is "it waits", your one-off will arrive late.

Quote clarity is the cheapest thing you can demand. A usable quote lists material grade and form, the machine class, the number of setups, any secondary operations, the finish spec, the inspection level and the packing. It also states what is excluded. If the quote says "machining" and nothing else, expect change orders. Ask for the routing in writing before you issue the PO, especially on a part with more than two operations.

Confidentiality belongs in this section because it affects timing. If your drawing cannot be released without an NDA, settle that first. Uploads should be secure and confidential, and an NDA should be available on request without a negotiation. A shop that hesitates on a standard NDA is telling you how it treats drawings in general.

• 1
  QuotingPrice plus DFM feedback, in hours not days
• 2
  MaterialIn-stock bar or mill order, stated explicitly
• 3
  ProductionMachine time plus inspection, quoted separately

Four certificates come up again and again in turned parts sourcing, and they cover different risks. ISO 9001:2015 is the general quality management baseline. IATF 16949:2016 adds automotive-specific requirements on traceability, change control and process capability. ISO 13485:2016 is the medical device quality standard. ISO 27001:2022 covers information security, which is what actually protects your drawings and CAD files. A shop with all four has been audited on quality, automotive discipline, medical traceability and data handling.

The scope line on the certificate is the part that matters. A certificate issued to a trading office does not cover a machining floor. Check the legal entity, the site address and the expiry date. For automotive work, confirm that the certificate covers the process you are buying, not just assembly or warehousing. If the supplier cannot send the certificate as a PDF, that is your answer.

Inspection records sit under the same heading. A 100% inspection claim is only meaningful with a plan behind it: raw material verification, in-process monitoring at defined intervals, and a final inspection before shipment. Reports should be available on request, and for a first article you should ask for dimensional data on the features that matter, not a pass/fail stamp. Our documented qualification rate is 99.99%, and it comes from that routine rather than from luck.

Materials and finishes expand the audit surface. If the part is anodized, plated or powder coated, the finishing supplier is part of your supply chain even if your machinist subcontracts it. Ask who does the finish, whether it is in-house, and how the parts are packed between the two steps. Turned threads and bores are easy to damage in transit, and a dented thread is a rejected lot.

• 1
  ISO 9001:2015Baseline QMS; check the site scope
• 2
  IATF 16949:2016Automotive traceability and change control
• 3
  ISO 13485:2016Medical device process control
• 4
  ISO 27001:2022Information security for your drawings

Aluminium covers most turned parts. 6061-T6 and 6082 are the default for housings and brackets, 7075 for high-strength fittings, 2024 where fatigue matters. They machine fast and hold tight tolerances, which keeps the price predictable. The exception is thin-wall aluminium: at 1 mm wall on a 60 mm diameter, chuck pressure alone can ovalize the part, and the shop has to switch to expanding mandrels or low-pressure clamping. Mention thin walls in the RFQ.

Stainless and steel are where turning earns its keep on strength. 303 is the free-machining grade and the cheapest stainless to turn, but it is not ideal for corrosive service. 304 and 316L turn harder and are the usual choice for food, medical and marine parts. 17-4PH (SUS630) offers high strength after heat treatment and is common in aerospace and valve work. On 4140 and 4340, pre-hardened stock saves a heat-treat step but costs more per kilogram; run the numbers both ways.

Copper and brass parts look simple and are not. C110 copper is soft and gummy, so it tears unless the shop uses sharp, polished tooling and generous coolant. C36000 brass is the opposite: it machines beautifully and produces fine chips, which makes it the standard for fittings and connectors. Beryllium copper is a special case; it needs controlled handling and the shop should say so before you ask.

Finishes should be chosen by function. Hardcoat anodizing for wear surfaces, clear anodizing for appearance, electroless nickel for corrosion and solderability, black oxide for optics and tooling. Bead blasting gives a uniform matte before anodizing; polishing is for appearance only and does not improve tolerance. Laser marking needs a minimum character height of 1.5 mm to stay readable, so design your part number accordingly.

• 1
  Aluminium6061-T6, 6082, 7075, 2024, 5052, 5083, ADC12
• 2
  Stainless303, 304, 316L, 17-4PH, 420, 440C
• 3
  Copper and brassC110, C36000, beryllium copper
• 4
  Titanium and specialTC4 (Ti-6Al-4V), Inconel, magnesium AZ31B
