Efficient production is not the same as the cheapest quote. It means the part meets the drawing the first time, the process repeats on the next order, and nobody spends a week chasing a deviation report. A shop with 127 high-precision CNC machines and 16 simultaneous 5-axis centers can absorb a design change mid-run. A shop with three machines cannot.

The starting point is your drawing. If the tolerance block says ±0.005 mm but only two features need it, the rest of the part still gets measured against that block by most inspectors. Relax the general tolerance and call out the tight features. That single edit often removes 20 to 30 percent of machine time, because the operator stops chasing a number the part does not need.

Material choice matters just as much. Aluminium 6061 and 7075 cut fast and hold ±0.005 mm well. Stainless 316L and titanium TC4 (Ti-6Al-4V) move under heat, so they need slower feeds, more coolant and sometimes a stress-relief step between roughing and finishing. Inconel and magnesium AZ31B sit at the far end: few shops keep them in stock, and the learning curve shows up in your lead time.

So before comparing prices, decide what the part must do. A bracket that holds a cable tray and a bracket that holds a hydraulic manifold look similar on screen. They do not belong in the same tolerance class, and quoting them as if they do is how projects slip.

• 1
  Functional features firstMark the datums and the fits that carry load or seal fluid.
• 2
  One general tolerance blockKeep it realistic; call out exceptions individually.
• 3
  Note the material conditionT6, annealed, or as-cast changes the cutting strategy.

Ask five questions and write the answers into the PO. First, what tolerance can you hold across the whole batch, not just on the first article. Second, what is the actual production lead time measured from drawing release. Third, is there a minimum order quantity, and does it apply to prototypes. Fourth, which certifications cover the plant doing the work. Fifth, how is inspection documented.

On tolerance, ±0.005 mm is achievable on a 5-axis center with temperature control, but it should not be the default. Most industrial parts run comfortably at ±0.05 mm, and many at ±0.1 mm. The cost curve is not linear. Going from ±0.1 mm to ±0.01 mm can double the cycle time, because the operator takes a spring pass and the CMM queue gets longer.

On lead time, separate the quote clock from the production clock. A useful benchmark from our floor: quotation and free DFM analysis within 12 hours, production start within 24 hours of PO and material release, and parts shipping in 3–5 days for standard geometries. If a supplier quotes a shorter window without stating when the clock starts, treat the number as marketing.

On MOQ, the honest answer for many buyers is that they need one piece first. No minimum order quantity means you can run a single prototype, measure it, then scale to 10,000+ part runs with the same supplier and the same fixture logic. That continuity is worth more than a few cents per part.

On certification, read the scope statement. ISO 9001:2015, IATF 16949:2016, ISO 13485:2016 and ISO 27001:2022 cover different things: general quality, automotive, medical devices, and information security. A medical implant house and an automotive tier-1 supplier need different documents even if both parts come off the same mill.

• 1
  Batch tolerance, not first-article toleranceAsk for the process capability, not the best single result.
• 2
  Clock start definitionPO date, material in-house date, or fixture approval date.
• 3
  Certificate scopeWhich plant, which process, valid until when.

The first failure point is the fixture. A supplier wins the job on a low price, then builds a soft jaw that flexes under load. The first 50 parts pass, part 51 drifts, and the batch is scrapped. Ask how the fixture is located and whether it repeats on the next order. For a 4,000 mm part, the answer usually involves a dedicated plate and a dial indicator, not a vise.

The second failure point is finishing. Machined surfaces at Ra 1.6–3.2 μm are fine for most structural parts. Sealing faces and bearing bores usually need Ra 0.8–1.6 μm, and optical or fluid-handling surfaces can need Ra 0.2–0.8 μm. Anodizing adds 5 to 15 μm per surface depending on the type, so a bore that is already at the low end of the tolerance can close up after coating. Call out pre-plate dimensions.

The third failure point is documentation. A supplier that cannot produce a material certificate and a dimensional report on request will cost you time during incoming inspection. We inspect 100 percent of parts before shipment, with raw material checks, in-process monitoring and a final inspection, and reports go out on request. That is the baseline, not a premium service.

The fourth failure point is communication. Time zone gaps and language gaps turn a two-hour question into a two-day delay. A supplier in Dongguan or Singapore with an English-speaking engineering contact removes most of that friction. Historical late-delivery probability below 2 percent does not come from fast machines alone. It comes from answering the email.

• 1
  Fixture repeatabilityAsk what locates the part on order two, not just order one.
• 2
  Coating allowanceState pre-plate dimensions for any bore that fits a mating part.
• 3
  Inspection reportConfirm what is measured and in what format before the run starts.

Three-axis milling handles the majority of prismatic parts: plates, housings, brackets and covers. It is the fastest route to a quote and the cheapest per hour. Its limit is reach. If a feature sits on five faces, you either run five setups or move to 4-axis and 5-axis work.

Four-axis machining adds a rotary axis, usually Ø400 mm, so the part turns while the tool cuts. Cross holes, slots on a cylinder and features on four sides come off in one setup. Concentricity improves because the part is not re-chucked between operations. For shafts and rotary manifolds, this is usually the right call.

Simultaneous 5-axis is for contoured surfaces and features that cannot be reached without tilting the tool. Impellers, turbine blades, orthopedic implants and complex automotive brackets fit here. The trade-off is programming time and a higher hourly rate, so it only pays when the geometry demands it or when one setup replaces four.

For very large parts, size decides the shop. Our large travel is 4,000 × 400 × 150 mm, with medium travels at 750 × 1,150 × 550 mm and 600 × 600 × 600 mm. If your part is 2 m long, most suppliers cannot quote it at all. If it is 200 mm, almost anyone can, and you should compete on lead time and inspection instead of on size.

• 1
  Prismatic, 3-axisPlates, covers, brackets: cheapest and fastest.
• 2
  Rotary, 4-axisShafts and cross-drilled parts in one setup.
• 3
  Contoured, 5-axisBlades, impellers, implants, complex brackets.
