A finished device is usually an assembly, not one part. A rechargeable product might contain a machined aluminium shell, a stainless steel motor cradle, a threaded end cap, a stainless button insert and a silicone over-mold. CNC processed sex toy production refers to the machined portion of that bill of materials: the rigid parts that carry load, threads, seals or motors.

Soft body-contact surfaces are a different process. Silicone and TPE are molded, because no cutting tool leaves a surface that feels right against skin. What the machined part does is give the silicone something to wrap around, hold a motor on axis, and close the housing with a seal that survives repeated opening.

So the practical question is not whether to use CNC or molding. It is which parts should be cut, and what the cut faces must achieve: a bore concentric enough to keep vibration low, a thread that does not gall after 500 charge cycles, and a surface that plating or anodizing will accept.

One more boundary. Machining does not sterilize, certify or approve a device for sale. We cut to your drawing and your tolerances. Biocompatibility testing, electrical safety and market approvals stay with you and your test lab.

A shell that tapers, twists or follows a body curve cannot be reached by a tool approaching from one direction. On a 3-axis machine you break the part into two or three setups, and each setup adds a re-clamp error. On a simultaneous 5-axis center the tool tilts while it cuts, so the outer blend and the internal cavity come off one datum.

That matters most at wall thickness. When a machined shell is going to be over-molded with 3–5 mm of silicone, the metal wall may only be 1.2–2.0 mm thick. If the two setups disagree by 0.05 mm, the silicone thickness varies by the same amount, and a thin spot can read as a hard edge through the cover.

Undercuts and internal channels are the second reason. A motor pocket with a wire channel that turns 90° is trivial to tilt into and hard to reach otherwise. Our 5-axis centers cover travels from 500 × 500 × 450 mm up to 4,000 × 400 × 150 mm, with a Ø400 mm rotary table for parts that need continuous rotation.

Not every part earns 5-axis time. A flat end cap with two holes is cheaper on a 3-axis mill. We quote the simpler route when the geometry allows it, and say so in the DFM notes.

The metal never touches the user directly in a well-designed device, but it still has to survive cleaning, sweat and time. Aluminium 6061-T6 is the default for shells: light, easy to anodize, and strong enough for M3 threads. Hardcoat anodizing adds a wear layer that resists keys and travel cases.

Stainless 316L is the usual pick for anything that contacts moisture, seals or threads that open often. It resists pitting better than 303 and machines cleanly at moderate feeds. For motor cradles and weight inserts, 303 or 304 is cheaper and machines faster. Titanium TC4 (Ti-6Al-4V) shows up in premium bodies where weight and corrosion both matter.

Plastics have a place too. POM and PEEK machine into low-friction internal guides, and PEEK tolerates steam cleaning. ABS and PC are common for prototype housings before tooling is cut. We stock 6061, 6061-T6, 2024, 5052, 5083, 6063, 6082, 7075, 303, 304, 316, 316L, 17-4PH, POM, PEEK, ABS, PC and PMMA.

Avoid mystery alloys. A supplier who cannot name the mill certificate cannot tell you what leaches out of a plated part after two years. Ask for the material grade in writing before the first chip is cut.

Most of a shell can live at ±0.1 mm. Three features cannot. Motor bores usually need ±0.02 mm to keep vibration down. Threaded closures need a controlled pitch diameter so the cap does not loosen in a bag. O-ring grooves need a groove width and depth that match the seal, typically ±0.05 mm.

General machining runs to ±0.005 mm when a drawing calls for it, and we inspect against that number rather than assuming it. Surface finish follows the same logic. Ra 1.6–3.2 μm is fine for hidden internals. A visible anodized face wants Ra 0.8–1.6 μm, and a polished stainless ring can go to Ra 0.2–0.8 μm.

Finishing is where a device stops looking like a machined block. Anodizing in clear, colour or hardcoat; electroless nickel; bead blasting for a matte grip; laser marking for logos and settings. Laser marking has a minimum character height of 1.5 mm, so fine text needs a different method.

Every part gets a raw material check, in-process monitoring and a final inspection before it ships. Inspection reports are available on request. If a dimension is marginal, we flag it before shipment rather than after.

Silicone bonds to metal only when the metal is prepared for it. A bead-blasted or primed surface gives the elastomer something to grip. A mirror-polished face gives it nothing, and the cover peels at the seam within months. This is a design decision made at the drawing stage, not at assembly.

Motor alignment is the second interface. If the cradle bore and the shell bore are cut in separate operations on different datums, the shaft sits off-axis and the device hums. Cutting both from one datum on a 5-axis center removes that stack-up.

Seals come third. An O-ring groove with a sharp internal corner will cut the ring during assembly. A 0.2–0.3 mm corner radius costs nothing and prevents a leak claim. We call these out during the free DFM review that comes with every quote.

For low-volume runs, prototypes often start as machined aluminium or POM while tooling for the silicone is still being cut. That lets you test fit, weight and balance before committing to a mold.

Machining has no tooling cost, so the first unit and the five-thousandth unit come off the same program. That is the practical advantage over injection molding for a new product. You can change the motor, add a button, or move a seal groove and only pay for the changed operation.

Our runs start at one piece and go past 10,000. Prototypes typically ship in 3–5 days after the program is proven, and production can start within 24 hours of a released drawing. Quotation and a free DFM analysis come back within 12 hours.

Where machining loses is unit cost at high volume. If a part is a simple flat shell and you need 100,000 pieces a year, molding will beat it. For complex geometry, low-to-mid volume, or a product line that still changes every quarter, machining stays competitive longer than most teams expect.

We run 127 high-precision CNC machines across three wholly-owned plants, including 16 simultaneous 5-axis centers, 16 mill-turn centers and 12 four-axis mills. That spread is what lets us route a job to the machine that fits it instead of the machine we happen to have.
