Most CNC machining design skills begin with one question: what is the part made of? Aluminium 6061-T6 cuts fast, holds a fine finish and lets you use thin walls. 7075 is stronger but more prone to movement after roughing. 316L stainless work-hardens, so a light feed rubs the surface instead of cutting it.

Titanium TC4 (Ti-6Al-4V) and Inconel push the other way. They hold heat at the cutting edge, so tool life drops and cycle time climbs. A geometry that machines in 20 minutes in 6061 can run past two hours in Inconel. Design the wall thickness and pocket depth around that difference.

Hardness drives tool choice too. 17-4PH in the H900 condition needs carbide and a rigid setup. Plastics such as POM and PEEK cut easily but deform under clamping pressure, so add support or leave a sacrificial web.

We machine aluminium, stainless, tool steel, copper, titanium, magnesium and engineering plastics. Tell us the alloy and temper in the RFQ, not just 'steel'. The grade decides feeds, speeds and whether a feature is even practical.

Walls are where thin-part problems show up. In aluminium, hold 0.8 mm or more for a wall that will be milled on both sides. Below that, the cutter pushes the wall away, the finish goes wavy and the caliper reads a different number every time.

Stainless and steel tolerate less flex, but they cut with higher force. Keep walls at 1.0–1.5 mm there, and thicker if the wall is tall. A 20 mm tall, 1 mm wall in 304 will sing during finishing no matter how sharp the tool is.

Floor thickness matters as much as walls. A 1 mm floor over a deep cavity deflects under the tool and leaves a witness mark on the opposite face. Add ribs, or accept a rougher finish on the back side.

If the part must be light, take material out of the middle of a pocket rather than thinning the outer wall. Removing 0.5 mm from a ribbed pocket costs less than removing 0.5 mm from a load-bearing wall.

A square internal corner cannot be milled. The cutter leaves its own radius, so a 6 mm end mill leaves roughly a 3 mm corner. If the drawing shows R0.5, the shop must switch to a 1 mm cutter, which is slow and snaps easily.

Match the corner radius to the depth. A pocket 25 mm deep with R1 corners needs a long, thin tool. It will chatter, and you will pay for the extra passes. R3 to R5 corners on the same pocket let one stubby cutter do the whole job.

Pocket depth also sets the limit. Past about 4 × tool diameter, chip evacuation gets difficult and the tool holder starts rubbing the top edge. Open the pocket with a wider entry, or split it into two shallower steps.

Blind pockets need a flat or corner-radius note. A ball-nose cutter leaves a curved floor, so a mating flat face will not sit flush. Say 'flat floor, R0.5 corner' if that is what the assembly needs.

Tolerance is the single biggest cost dial in a drawing. A ±0.1 mm general block and a hand-picked ±0.005 mm on two bearing bores costs far less than a title block that says ±0.005 mm everywhere.

Use the general tolerance for cosmetic faces, clearance holes and non-mating edges. Tighten only the features that set alignment, fit or sealing. A press-fit bore, a dowel hole and a bearing seat are the usual candidates.

Geometric callouts deserve the same treatment. Flatness on a gasket face is worth paying for. Flatness on an exterior face that nobody bolts to is not. Datum structure should follow the assembly, not the drawing order.

Surface finish tracks tolerance. Ra 0.8–1.6 μm covers most sealing and sliding contacts. Ra 0.2–0.8 μm needs a finishing pass and a polished tool, so reserve it for the few faces that need it.

Each time a part is re-clamped, position error stacks. A part machined in three 3-axis setups has three chances to drift. The same part on a 5-axis center can come off one setup with the datums intact.

Think about which faces the tool must reach. A hole on the side of a tall boss may need the part turned 90°, and that is a second operation. Moving the hole to a face already being milled often removes the operation.

Undercuts, deep side slots and features on five sides push the part toward 5-axis work or a mill-turn center. That is fine, and we have 16 simultaneous 5-axis centers plus 16 mill-turn centers. It still helps to know which feature caused the extra setup.

Add a clamping allowance when the part is thin or has no flat face for the vise. A small tab that gets cut off later is cheaper than a fixture built just to hold the part.
