A 5G radio unit concentrates roughly 200 W to 800 W into a package smaller than a shoebox. That heat has to leave through a chain: die, case, thermal interface material, radiator base, fins, air. Every joint in that chain adds resistance, and the worst joint sets the rate for the whole part.

Machining affects two links in that chain. The first is the base-to-case interface. A flat, smooth base lets the thermal pad or grease film stay thin and complete. A bowed or rough base traps air and forces the interface layer thicker, which raises resistance where the heat is densest.

The second link is the fin field. Heat spreads sideways through the base, then climbs each fin and leaves by convection. If fins are too thin, the tip runs much cooler than the root and the upper half of the fin does little work. If fins are too thick, you lose surface area for the same envelope.

So the design question is not how much aluminium to buy. It is how to shape a fixed volume so the fin roots stay close to the source temperature and the air can still pass through. That is a geometry problem, and geometry is what CNC holds.

• 1
  Base conductionSpreading resistance inside the base plate, driven by thickness and source footprint.
• 2
  Interface resistanceSet by flatness, roughness and the pad or grease film thickness.
• 3
  Fin conductionFalls off along the fin height as the tip approaches air temperature.
• 4
  ConvectionLimited by fin gap, ducting and the airflow the enclosure allows.

Fin efficiency drops as the fin gets taller relative to its thickness. For aluminium, a fin around 1 mm thick and 25 mm tall still runs fairly efficient. Push the same fin to 50 mm and the tip contributes much less per gram of metal. That is why tall thin fins often lose to a shorter, denser field with better airflow.

Gap width is set by the airflow, not by taste. Natural convection needs generous gaps, often 6 mm and up, or the boundary layers merge and the channels stall. Forced air with a clean duct can run 1.5 mm to 3 mm gaps. Below about 1 mm, dust loading and pressure drop start to cost more than the added area gains.

Aspect ratio, the fin height divided by gap, is the number worth tracking. Around 10 to 20 works for forced air in a clean enclosure. Above 30 the flow has to be very well guided or the fins simply recirculate hot air.

CNC machining earns its place here because it cuts the fin field from one solid block. There is no bond line between fin and base, so the joint resistance is effectively zero. Bonded or soldered stacks can be excellent, but the interface has to be controlled and inspected, and that is a process cost of its own.

• 1
  Dense field1.5–3 mm gaps, forced air, 15–25 mm fin height.
• 2
  Open field6–10 mm gaps, natural convection, keep fins under 40 mm.
• 3
  Monolithic cutFins and base from one billet, no bond line, best for low to mid volume.

Flatness is the specification that most often decides whether a radiator meets its thermal target. A base that bows 0.05 mm across a 100 mm footprint leaves a wedge of air in the middle or at the edges, depending on the bow direction. Even a good thermal pad cannot fully recover that.

Roughness works the same way, but it saturates. Going from Ra 3.2 μm to Ra 1.6 μm usually shows a measurable drop in interface resistance. Going from Ra 0.8 μm to Ra 0.4 μm rarely shows anything you can measure on a finished unit, because the pad or grease already fills the valleys.

There is a practical floor. On aluminium, holding Ra 0.2–0.8 μm across a large base is achievable, but it costs time and needs sharp tooling and stable fixturing. Ask for it when the interface is a thin grease film or a bare metal contact, not when a 1 mm gap pad is doing the work.

Thin bases bow during machining. Rough out, stress relieve if the stock allows, then take light finishing passes on both sides. Taking the last 0.3 mm off one face only is a reliable way to build in a bow you will fight later.

Most communication radiators we run start as 6061-T6 or 6063 extrusion or plate. 6061 machines cleanly, takes anodizing well and holds flatness after a proper sequence. 6063 gives slightly better thermal conductivity and a nicer anodized finish, but it is softer and gummier to cut, so chip control matters more.

The sequence is roughly the same every time. Face the base, rough the fin slots with a coarse pitch, let the part cool and settle, then finish the base and the fin walls in a single setup where possible. Finishing the base in a second setup invites a mismatch between the base plane and the fin roots.

For tall or thin fin fields, a five-axis or a four-axis setup with a rotary table lets one tool reach the whole field without repositioning the part. That keeps fin wall thickness consistent from one end to the other, which matters when the field is 300 mm long or more.

Inspection is the part most buyers under-specify. We check flatness on the base, sample fin thickness and gap, and verify the mounting hole pattern. Reports are available on request, and the whole run is inspected before shipment. If flatness is your critical dimension, say so on the drawing rather than in an email.

• 1
  Material6061-T6 for flatness and strength; 6063 for conductivity and finish.
• 2
  SetupBase and fin roots finished in one setup to avoid a plane mismatch.
• 3
  InspectionFlatness, fin thickness, gap, hole pattern; reports on request.

Past a point, tightening the machining tolerance does not lower junction temperature. If the bottleneck is the airflow through the enclosure, a base held to ±0.005 mm will not rescue it. Measure or estimate the air-side resistance before you spend money on micron-level flatness.

Very dense fin fields also hit a pressure limit. A 0.8 mm gap field looks great on a surface-area spreadsheet, but the fan has to push air through it. If static pressure at the operating point is low, the flow short-circuits over the top of the fins instead of through them.

Material choice has a ceiling too. Aluminium sits near 170–200 W/(m·K) depending on alloy and temper. Copper is far better, but it is roughly three times the weight and harder to machine thin. For most radio units, better geometry beats switching to copper.

Finally, remember the mounting. A perfectly flat base clamped by four bolts at the corners still bows under load if the housing face is not flat. Interface performance is a system property, not a single-part property.
