A tolerance figure on a quote means nothing until you know which features it applies to. A shop can hold ±0.005 mm on a 20 mm bore and still miss a 600 mm frame by 0.05 mm, because the error budget shifts with part size, fixturing and thermal growth during the cut. When you compare CNC machine services or 97078 suppliers, ask for the tolerance per feature group, not one number for the whole print.

Inspection is the second half of the same question. A supplier that runs raw material checks, in-process monitoring and a final inspection before shipment can show you the sequence. A supplier that only measures at the end is inspecting scrap, not making parts. Ask whether reports come with the shipment or on request, and in what format.

Units matter more than people expect. If your drawing is in inches and the shop programs in millimeters, confirm the conversion limit. ±0.0002 in is roughly ±0.005 mm, and a rounding slip at that level eats the whole tolerance band on a press-fit pin.

Surface finish sits in the same conversation. Ra 0.8–1.6 μm is a normal machined finish for sealing faces. Ra 0.2–0.8 μm needs a finer step-over or a secondary operation, and that changes both price and schedule.

Buyers usually treat lead time as one number. It is two. The first is engineering time: how fast the shop returns a quotation and a DFM analysis. The second is machine time, which depends on queue depth, setup count and how many operations your part needs. A fast quote with a slow queue is still a slow part.

Setup count is the hidden multiplier. A part that needs one vise setup on a 3-axis mill moves quickly. A part with five faces of work, tight true position between bores and a thin wall needs 5-axis or multiple fixtures. Sixteen simultaneous 5-axis machining centers in one shop reduce the number of times a part is re-clamped, and every re-clamp is a chance to lose position.

Material availability drives the rest. Aluminum 6061 and 7075, stainless 303 and 316L, and 17-4PH are common stock. Inconel and titanium TC4 often need to be ordered, and that wait does not appear on a machine schedule.

Ask what happens when a job runs late. A shop that tracks its own late-delivery rate can tell you the number. One that answers with adjectives cannot.

Order size tells you which shop you are talking to. A prototype house is set up for one-off setups and quick programming. A production shop is set up for repeat fixtures and cycle-time tuning. Some shops do both, and those are the ones worth a first call, because you avoid re-qualifying a supplier when the design freezes.

A shop with no minimum order quantity can take a single prototype and later a 10,000-part run on the same process sheet. That continuity matters for medical and automotive work, where a process change between prototype and production triggers a fresh validation.

Pricing follows geometry, not weight. Deep pockets, sharp internal corners, threads finer than M2 and walls under 0.8 mm on aluminum all add cost. So does a tolerance callout tighter than the function needs. If a bore only locates a bushing, holding ±0.005 mm there buys nothing and costs money.

Finish is a separate line item. Anodizing, electroless nickel, powder coating, bead blasting and laser marking all add days. Get them quoted together with machining so nobody discovers the plating step after the parts are cut.

Certification is not a ranking. It is a match. ISO 9001:2015 covers general quality management and satisfies most industrial machinery and robotics work. IATF 16949:2016 is what automotive and EV programs expect. ISO 13485:2016 applies to medical devices. ISO 27001:2022 covers information security, which matters when your files are the product.

Ask for the certificate scope, not the certificate. A valid ISO 13485 certificate that lists machining of implant components is a different document from one covering packaging. The scope line is where the real answer sits.

Confidentiality belongs in this check. Uploads should be handled as confidential by default, and an NDA should be available on request rather than negotiated from scratch. If your design is the only asset you have, that clause is not paperwork.

Traceability closes the loop. Material certificates, heat lot numbers for 17-4PH and titanium, and inspection records should be tied to the shipment. Without them, a field failure has no path back to a cause.

Machine lists are boring until your part does not fit. Ask for travels and table size, then compare against your envelope. Common configurations cover 500 × 500 × 450 mm, 600 × 600 × 600 mm and 750 × 1,150 × 550 mm. Long parts need something larger, up to 4,000 mm of processing length.

Axis count decides geometry. Three-axis machines handle prismatic parts with work on one face. Four-axis mills add rotation for slots and holes around a cylinder. Five-axis centers cut undercuts and compound angles in one setup, which is how you hold position between features that cannot be reached from a single direction.

Mill-turn centers matter for parts that are mostly round with milled flats or cross holes. Cutting a shaft in one machine avoids the concentricity error that comes from moving it between a lathe and a mill.

Tooling and workholding deserve a question too. A Ø400 mm rotary table handles larger round parts. Thin-wall housings need soft jaws or custom fixtures, and a shop that quotes those upfront is a shop that has cut them before.
