A retrofit strips the electronics off a working machine tool and puts new ones on. Sometimes it also regrinds or re-scrapes the mechanical slideways. The two halves are quoted separately because they fail separately. A 2005 machining center with a dead control but tight ballscrews is a control job. The same machine with 0.03 mm of lost motion on the X axis needs mechanical work first.

That split is where most quotations go wrong. Vendors who only sell control packages will quote a control package. They are not lying, but they are answering a different question than the one the part is asking. Before you ask for a price, decide which physical symptom you need gone: position drift, chatter over the whole table, a spindle that will not hold speed under load, or an operator spending an hour a day nursing alarms.

The mechanical side covers ballscrews, linear guides or box ways, spindle bearings, lubrication lines, and the squareness of the column to the table. The electrical side covers the CNC controller, servo drives, spindle drive, motors, I/O, cabling, and the safety circuit. A complete rebuild touches both. A partial one does not, and the quotation should say so on the first page.

• 1
  Control-onlyFastest route back to production. Leaves worn mechanics in place.
• 2
  Mechanics plus controlRestores accuracy, not just function. Weeks, not days.
• 3
  Automation linkAdds data output, probing or robot load. Independent of wear.

You cannot judge a machine from the screen. Put an indicator on it. Check squareness between X and Y over the full travel, then check Z perpendicularity to the table. On a 750 × 1,150 × 550 mm machine, a squareness error of 0.02 mm per 300 mm will show as a tapered bore on any interpolated feature, and no amount of servo tuning hides it.

Then measure backlash on each axis at both ends of travel. Ballscrew backlash under 0.01 mm is normal and can be compensated. Over 0.03 mm usually means the screw, the nut, or the thrust bearings are done. Check the ways for scoring. Pull the way covers back and look. If you cannot see bare metal, ask why.

Spindle runout matters as much as the axes. Indicate the taper: 0.005 mm TIR on a new spindle is normal, 0.02 mm is a bearing job. If the spindle growls at 8,000 rpm or the tool pulls out during a heavy cut, the rebuild quote needs a spindle line item, not a footnote.

• 1
  SquarenessIndicator over full travel. Ask for the number, not a pass or fail.
• 2
  BacklashUnder 0.01 mm is compensable. Over 0.03 mm is a mechanical repair.
• 3
  Spindle TIR0.005 mm is healthy. 0.02 mm means new bearings.
• 4
  Way conditionPull the covers. Scoring and pitting rule out a control-only job.

Control choice is usually driven by what your operators already know and what your other machines use. If your shop runs one brand, adding a second brand costs more in training and tooling than the hardware saves. That is a real cost. Say it out loud in the supplier meeting.

Ask for part numbers, not brand names. A quotation that says new control and new drives is not a quotation. It should list the controller model, the number of axes, the drive models, and the motor models. On a 4-axis mill with a Ø400 mm rotary table, the rotary drive is often the item that quietly gets dropped from the scope.

Obsolete drives are the most common cause of a retrofit stalling halfway. If the replacement drive takes 14 weeks to arrive, your machine sits dead for 14 weeks. Ask the supplier to confirm stock or lead time in writing before the deposit clears. If they cannot, the rebuild schedule is fiction.

• 1
  Match your shop standardOne control brand across the floor cuts training and spares.
• 2
  Demand part numbersController, drives, motors, encoders. Every axis listed.
• 3
  Confirm drive lead timeA 14-week drive turns a 2-week job into a 16-week outage.

Ignore any quoted accuracy figure that is not tied to a measurement method. A rebuilt machine should be handed over with a test record, not a handshake. The record should cover positioning accuracy and repeatability on each axis, squareness, and a test cut result.

For most rebuilt milling machines, a working target of ±0.005 mm on a test feature is achievable when the mechanics were rebuilt. If the supplier only swapped the control and drives, expect the machine to reproduce its old geometry, not to improve it. The control will hold position better than the worn screw can, which is why a control-only job often feels accurate but cuts tapered.

Run a test cut in your own shop on your own material. A 100 mm circle interpolated in aluminium, measured on a CMM, tells you more than a calibration certificate. Watch the surface finish on a finishing pass at Ra 0.8–1.6 μm; if the machine chatters where it used to be quiet, the mechanical scope was too thin.

• 1
  Test record requiredPositioning, repeatability, squareness. Signed and dated.
• 2
  Control-only caveatPosition improves. Geometry does not.
• 3
  Cut your own test partInterpolated circle, measured. Finish check on the same setup.

A retrofit stops production. That is the real cost, and it dwarfs the invoice on a busy machine. Ask the supplier to break the schedule into three parts: teardown and measurement, mechanical work, and electrical work plus commissioning. Each part has a different crew and a different risk.

Control and drive work is often quoted at 3–7 days of machine downtime. Mechanical rebuilds run 3–5 weeks, and a full rebuild can reach 6–10 weeks. If the supplier quotes 5 days for a job that includes grinding the ways, the schedule is wrong or the scope is. Either is a problem.

Plan the window around your order book, not around the supplier's convenience. If the machine must run through a peak month, the rebuild waits. A supplier who pushes you into a bad window is optimizing their shop, not yours. Get the schedule in the contract with a stated start date.

• 1
  Three-phase scheduleTeardown, mechanical, electrical. Separate dates and owners.
• 2
  Downtime realityControl-only 3–7 days. Full rebuild 6–10 weeks.
• 3
  Your calendar firstPick the window around your order book, then negotiate.

Retrofitting is not always cheaper. It is cheaper when the iron is good and the electronics are dead. It stops being cheaper when the casting has cracks, when the ways are worn through their adjustment range, or when the machine has been crashed hard enough to move the column.

A cracked casting at a mounting face is usually terminal. Welding and re-machining a machine base costs more than a used machine of the same size, and the result is still a repaired casting. If the supplier proposes welding without a stress-relief plan, walk away.

There is also a throughput argument. A rebuilt 3-axis machine still has 3 axes. If your work has moved to parts that need 5-sided access in one setup, a rebuild restores an old capability at full cost. In that case, the money belongs in a 5-axis machine, and the old machine should be sold or kept for roughing.

• 1
  Cracked castingUsually terminal. Repair cost often exceeds a used machine.
• 2
  Ways past adjustmentIf grinding cannot restore geometry, the rebuild has no floor.
• 3
  Capability gapA 3-axis rebuild does not become a 5-axis machine.

Ask what the supplier will hand over at the end. You want electrical schematics as built, a parameter backup of the control, a list of every replaced part with its part number, and a test record. Without those four items, the next fault is a mystery and your maintenance team pays for it.

Check the quality system behind the rebuild. A shop running ISO 9001:2015 and, where relevant, IATF 16949:2016 or ISO 13485:2016 has documented inspection steps and traceability. That matters if the machine produces medical or automotive parts and your customer audits the process.

If your parts are sensitive, ask about data handling. ISO 27001:2022 covers information security management. Uploads and drawings should be treated as confidential, and an NDA should be available on request rather than negotiated as a favor. A supplier who hesitates here is telling you something.

• 1
  Four handover itemsSchematics, parameter backup, part list, test record.
• 2
  Quality systemISO 9001 base. IATF 16949 or ISO 13485 if your parts need it.
• 3
  ConfidentialityISO 27001:2022, secure uploads, NDA on request.

GreatLight has run machining operations in Dongguan since 2011, with 3 wholly-owned plants covering 7,600 m² and 150 technicians. That background matters here for one reason: we rebuild machines to hold the tolerances we already have to hold on production parts, ±0.005 mm, with 100% inspection before shipment and reports on request.

Our shop runs 127 high-precision CNC machines, including 16 simultaneous 5-axis machining centers and 16 mill-turn centers. When a customer's retrofit is risky, we can move the work onto our own capacity while the rebuild happens, so the order book does not stop. That is a practical answer to the downtime problem, not a sales line.

Where a retrofit is clearly the wrong call, we say so. If the geometry measurement shows a terminal casting or ways past adjustment, we will tell you and quote the machining work instead. The certifications behind our process are ISO 9001:2015, IATF 16949:2016, ISO 13485:2016 and ISO 27001:2022, and they apply to how we document a rebuild as much as to how we cut a part.

• 1
  Built on machining15 years, 3 plants, 150 technicians, 127 CNC machines.
• 2
  Production coverParts can move to our machines while yours is down.
• 3
  Straight answersIf the iron is gone, we quote machining, not a rebuild.
