Z runs along the spindle centerline on a two-axis lathe, while X is measured as a diameter rather than a radius. That single convention causes most of the confusion in CNC lathe theory test questions about coordinates. A program move of X 20.0 does not put the tool 20 mm from the centerline; it puts the cutting edge 10 mm from it.

Machine zero usually sits at the spindle face or at the chuck reference. Work coordinates are then shifted so that Z0 lands on the finished face of the part. Every dimension in the drawing is referenced back to that face, which is why operators touch off the face tool first and check the remaining offsets against it.

Radius programming exists on some controls, but you must switch it on deliberately. If the control is set to diameter mode and the programmer writes radius values, every X move doubles. The part gets cut oversized by a factor of two, and the error only shows up after the first pass. Test questions often ask which mode is active for exactly this reason.

Chamfers and radii on a turned profile need the same care. A 2 × 45° chamfer is measured along the axis and along the diameter, not along the tool path. When the drawing calls out a corner radius of R3, the insert nose radius must be compensated through the tool offset, not simply added into the coordinate.

• 1
  Diameter mode is the defaultMost fanuc-style controls treat X as a diameter value.
• 2
  Touch off the face firstZ0 on the finished face anchors every other offset.
• 3
  Check the mode before the first cutA radius value in diameter mode doubles the part.

A tool offset tells the control where the cutting edge actually is. Geometry offset covers the difference between the turret station and the theoretical tool tip. Wear offset covers the small changes that appear as the insert dulls. Both are added to the programmed coordinate at run time, and mixing them up is a classic failure in CNC lathe theory test questions.

Nose radius compensation matters on any profile that is not a straight line parallel to an axis. An insert with a 0.8 mm nose radius cannot cut a sharp internal corner. The control has to shift the tool path by the radius and blend the corner. Skip that step and the part comes out with a corner that is visually wrong but dimensionally close enough to pass a casual check.

Wear offset drifts in one direction on most turning operations. Facing and boring tend to push the tool away from the workpiece, so the X wear value creeps upward over a run. A 40-part run at ±0.005 mm tolerance will not hold if the operator never touches the wear page.

When a test asks what to do after a tool change, the answer is rarely about the program. It is about re-establishing the geometry offset on the new insert and confirming it with a test cut before running production.

• 1
  Geometry offsetFixed position of the tool tip in the turret.
• 2
  Wear offsetSmall corrections that follow insert wear.

Surface speed is the starting point for any turning calculation. The formula is simple: V = π × D × N / 1000, with V in m/min, D in mm and N in rpm. What the formula hides is the material factor. Aluminum 6061 runs happily at 300–500 m/min with carbide. Inconel wants 20–40 m/min and will destroy an insert in seconds if you push it.

Feed per revolution controls chip thickness on a turning tool. Too light a feed rubs the insert instead of cutting it, which work-hardens stainless and shortens tool life. A typical roughing feed on 304 stainless is 0.15–0.25 mm/rev. Finishing passes drop to 0.05–0.10 mm/rev to hit Ra 0.8–1.6 μm.

Depth of cut is set by the insert geometry and the machine rigidity, not by the drawing alone. A 4,000 mm shaft on a lathe with a Ø400 mm rotary table and a long overhang will chatter long before the insert reaches its rated depth. Test questions rarely mention rigidity, but the shop floor never forgets it.

Threading adds one more number. The feed for a thread pass equals the pitch, so an M10 × 1.5 thread runs at 1.5 mm per revolution. Depth per pass shrinks as the thread gets deeper, because the contact area grows with each cut.

• 1
  Surface speed drives insert lifeMatch V to the material, not to the machine.
• 2
  Feed sets the finishLight feeds work-harden stainless and shorten tool life.
• 3
  Rigidity caps depth of cutLong overhangs chatter before the insert is loaded.

A thread is checked with three wires of a known diameter, placed in the thread grooves. The measured over-wire dimension is then compared against the calculated value. For a metric thread the wire diameter works out near 0.577 × pitch. A 1.5 mm pitch thread therefore needs wires around 0.866 mm.

The three-wire method measures the pitch diameter, which is the dimension that actually controls fit. Major diameter can look perfect while the pitch diameter is out of limits, and the thread will still fail a go/no-go gauge. That gap between appearance and function is what most CNC lathe theory test questions on threads are testing.

Thread depth is usually cut in several passes because the chip load grows quickly. A 60° thread form removes more material per pass as the tool moves inward, so the first pass might be 0.3 mm deep on the radius and the last pass 0.05 mm. Skipping steps overloads the tip and breaks it.

Thread profile also depends on the insert angle. A 60° insert for metric threads will not cut a Whitworth 55° form correctly, even if the pitch matches. The flank angle is part of the geometry, not a cosmetic detail.

• 1
  Wire size follows pitchRoughly 0.577 × pitch for a 60° metric form.
• 2
  Pitch diameter governs fitMajor diameter alone tells you very little.

A turning drawing usually carries both a size tolerance and a geometric tolerance. Size tells you how big the feature is allowed to be. Geometric callouts control roundness, cylindricity, concentricity and runout, which size alone cannot capture. A shaft can sit perfectly inside its diameter limits and still be oval.

Concentricity and runout are the two callouts that turn up most on turned parts. Concentricity controls the axis of one feature relative to another. Runout controls the surface as the part rotates. On a part held in a three-jaw chuck, runout is often created by the chuck itself rather than by the cutting forces.

Roundness on a turned diameter depends on spindle condition and on how the part is supported. A thin-wall tube held only at one end will deflect under the cutting load and spring back into an oval. The fix is a steady rest or a softer finishing pass, not a tighter tolerance callout.

When a drawing asks for ±0.005 mm across a long shaft, the process has to be planned around thermal growth and deflection, not just around the insert. A test question that asks which tolerance is hardest to hold is really asking which one reacts to the machine, the fixture and the material at the same time.

• 1
  Size versus formDiameter limits say nothing about roundness.
• 2
  Runout comes from the fixtureChuck error shows up as runout on the part.

Aluminum cuts fast and forgiving, which is why it dominates turning examples. Grades 6061 and 7075 both machine well, though 7075 holds a better finish on thin sections. Chip control is easy with sharp inserts and a positive rake.

Stainless 304 and 316 behave differently. The material work-hardens at the surface, so a dull insert makes the next pass harder than the last. Cutting fluid and a steady feed matter more than raw speed. Grade 17-4PH in the H900 condition cuts more like a mild steel but wears inserts faster.

Titanium TC4 sits at the other end. Low thermal conductivity keeps heat in the cutting zone, so the insert edge reaches high temperature while the chip stays cool. Speed drops to 30–60 m/min and the coolant has to reach the edge, not just the part.

Copper alloys and brass machine cleanly and produce short chips. Beryllium copper is the exception. It cuts well but the dust needs control, and that is a process issue rather than a programming one.

• 1
  Aluminum: high speed, sharp edge6061 and 7075 turn cleanly at 300–500 m/min.
• 2
  Stainless: steady feedWork hardening punishes a light finish pass.
• 3
  Titanium: low speed, real coolantHeat stays at the cutting edge, not in the chip.
