Material is removed by a tool that turns fast and moves slowly. A typical engraving spindle runs 12,000 to 24,000 rpm, while the feed stays between 200 and 800 mm/min. Compare that with a milling cutter at 4,000 rpm and 1,200 mm/min and the difference is obvious: engraving trades roughing volume for edge definition.

At these speeds the cutting edge does not shear a chip the way an end mill does. A single-flute or half-round cutter contacts the work over a very short arc, often under 0.05 mm. The result is a shallow groove, usually 0.05 to 0.5 mm deep, held to a line width the tool tip itself defines.

That geometry explains why the tool tip, not the machine frame, sets feature size. A 0.2 mm tip produces a 0.2 mm line. Change the tip and you change the whole layout. Programmers who treat engraving like a scaled-down milling pass usually break tools in the first few minutes.

• 1
  Depth range0.05–0.5 mm per pass on most metals
• 2
  Typical spindle12,000–24,000 rpm with low runout
• 3
  Line widthSet by tool tip, not by stepover

Single-flute carbide cutters cut aluminum, brass and plastics cleanly. They clear chips well at high rpm and leave a sharp shoulder. The trade-off is fragility: a 0.5 mm single-flute tool snaps if the operator plunges faster than 50 mm/min into 6061.

Half-round and V-shaped tools suit fine text and mold texture. A 60° or 90° included angle gives predictable line width as depth changes, which matters when you engrave a curved surface. Diamond-tipped tools handle hardened steel and glass, but they chip if the spindle has more than 0.01 mm runout.

For deep features over 0.5 mm, engraving is the wrong process. Switch to a 2 mm end mill and accept a wider line. We see this often on part numbers that need 1 mm depth for traceability after anodizing: the cutter survives, but the letter edges round over.

• 1
  Single fluteAluminum, brass, plastics; sharp edges
• 2
  V-bit 60°/90°Text and texture; predictable width
• 3
  Diamond tipHardened steel, glass; needs low runout

Most engraving defects trace back to the setup, not the cutter. A plate that sits 0.1 mm high on one side produces a groove that fades to nothing across the part. Vacuum tables and soft jaws help only if the stock is flat within 0.02 mm.

Surface mapping solves this. We probe the top face on a grid, then the controller tilts the tool path to follow the real surface. This costs a few minutes per setup and removes depth drift entirely on plates up to 4,000 mm long.

Thin parts move during cutting. A 1 mm aluminum panel can flex 0.05 mm under a 0.3 mm depth of cut and leave chatter marks. Support it with a sacrificial backing plate, or reduce depth to 0.1 mm and run two passes.

• 1
  Flatness targetWithin 0.02 mm across the engraved area
• 2
  Surface probingGrid map corrects depth drift
• 3
  Thin stockBacking plate or 0.1 mm passes

Engraving suits shallow, high-contrast features: serial numbers, logos, grip texture, mold cavity labels. It struggles when you need depth for wear resistance, when the material work-hardens, or when the feature must survive a coating.

Anodizing adds about 0.01 to 0.02 mm of oxide and can fill a 0.05 mm groove. Laser marking holds contrast better on coated parts, while engraving wins when you need physical depth that a fingernail can feel.

For 316L stainless and titanium, work hardening dulls a carbide tip within a few hundred millimeters of cut. Expect to change tools mid-run, or move to laser marking. Neither process is universal, and the choice usually comes down to whether the mark must be tactile.

• 1
  Good fitShallow tactile marks, texture, serials
• 2
  Poor fitDeep grooves, work-hardening alloys
• 3
  Coating riskAnodize fills grooves under 0.05 mm
