The process is subtractive. A rotating cutter or a stationary turning tool removes material from a solid block until the geometry matches the CAD model. Nothing is formed, molded or sintered, so the mechanical properties of the stock material carry straight into the finished part. For an electronic enclosure or a heat sink, that matters. Thermal conductivity, electrical resistivity and stiffness come from the billet you bought, not from a process recipe.

The consequence is simple. Any feature the tool can reach can be cut to a known dimension, and features the tool cannot reach have to be redesigned, split into two parts, or moved to another process. That single constraint explains most of the cost differences between two quotes for the same drawing.

Workholding decides repeatability more than spindle speed does. A thin-walled housing clamped in a vise will bow between operations, and the second setup will not reference the same surface as the first. Fixturing on a machined pad, or leaving tabs that are cut off in a final pass, keeps the part where the model says it is.

Heat is the other quiet variable. Aluminium moves roughly 23 μm per meter per °C, so a 10 °C rise across a 300 mm plate shifts the part by about 0.07 mm. Rough the part, let it cool, then finish. On tight work we leave 0.3–0.5 mm of stock for the finishing pass and measure after the part has returned to room temperature.

Aluminium covers most electronic work: 6061-T6 for housings and brackets, 2024 where stiffness per gram matters, 7075 for RF cavities and connector bodies. All of them cut freely, hold threads well, and anodize cleanly. The softer grades, 5052 and 5083, resist corrosion better but gum up taps, so expect rolled threads or thread milling instead of cutting taps.

Copper and brass solve thermal and RF problems aluminium cannot. C101 and C110 copper conduct heat roughly twice as well as aluminium but machine gummy, so cutters need sharp edges and generous coolant. Brass C36000 is the free-machining option for waveguides and shield cans. Beryllium copper gets used for spring contacts, and it requires chip control because the dust is a health hazard.

Stainless and titanium appear where corrosion, vacuum compatibility or strength rule out aluminium. 304 and 316L are common for vacuum chamber walls; 17-4PH appears in load-bearing brackets. Titanium Ti-6Al-4V is stiff and light but conducts heat poorly, so heat concentrates at the cutting edge. Reduce surface speed and keep the tool moving.

Plastics behave differently again. POM and PC machine cleanly and hold ±0.05 mm without much effort. PEEK handles reflow temperatures and chemical exposure but is abrasive and expensive. Carbon fibre reinforced grades eat carbide unless you use diamond-coated tooling. Every plastic part needs a light finishing pass because the first cut leaves fuzz, not a surface.

Three-axis milling handles plates, lids and open housings where all cutting happens from one direction. Add a rotary table and a fourth axis and you can cut around the part in one setup, which removes the re-datum error that shows up when a housing is flipped by hand. Our Ø400 mm rotary tables cover most enclosures in this class.

Five-axis machining earns its cost when the part has angled faces, deep pockets with drafted walls, or port geometry that a straight tool cannot reach without hitting the opposite wall. RF cavities and antenna housings usually fall here. A simultaneous five-axis center cuts those faces in one continuous pass, so the surface has no witness lines and the wall thickness stays even.

Turning suits cylindrical electronics: connector shells, sensor bodies, standoffs, waveguide sections. A mill-turn center machines a turned body and mills flats, slots or cross-holes without a second setup. That combination is worth specifying when the drawing shows a turned OD plus flats that must be square to the bore within 0.02 mm.

Small features set their own limits. A slot 1 mm wide needs a cutter under 1 mm, and those break if the depth exceeds about three times the diameter. Threads below M2 are better rolled or cut on a lathe than tapped by hand. Minimum laser-marked character height is 1.5 mm, so part numbering below that has to be etched or printed instead.

As-machined finish from a clean cutter path lands around Ra 1.6–3.2 μm. That is enough for internal brackets and most non-visible parts. Bring it to Ra 0.8–1.6 μm with a finishing pass and controlled feed, and the surface is ready for anodizing or plating without extra prep. Finer than Ra 0.2–0.8 μm is reserved for sealing faces and optical mounts.

Anodizing changes dimensions. Type II clear or coloured anodize builds roughly 5–15 μm per surface, hardcoat more. If a bore has a ±0.01 mm fit, mask it or cut it undersize before coating. Conductive anodize exists for parts that need both a hard surface and electrical continuity to the chassis.

Plating is the other route. Electroless nickel gives a uniform layer on complex geometry and good corrosion resistance. Zinc and black oxide are cheaper but offer less wear resistance. Silver and gold plating appear on RF and high-frequency contacts where skin resistance matters, and both need a nickel strike underneath to bond to aluminium.

Mechanical finishes sit alongside coatings. Bead blasting hides tool marks and gives a matte texture that takes fingerprints less obviously than polished metal. Brushing produces a directional grain that shows on flat panels. Polishing is rarely worth it on electronics unless the part is visible to the end user.
