Tolerance on a drawing is a request. What the machine can hold is the answer. A 3-axis mill can hit ±0.005 mm on a flat plate with one setup and shallow pockets. Add a fourth side, a deep cavity or a compound angle and the part needs repositioning, which stacks error.

This is where 5-axis and mill-turn centers earn their cost. One setup means one datum. Features on five faces stay in relation to each other because the part never leaves the fixture. For housings, manifolds, impellers and angled ports, the tolerance gain is usually bigger than any programming trick.

Size sets the limit too. Our largest envelope runs to 4,000 mm, with 4,000 × 400 × 150 mm travel on the long machines. Medium work sits at 750 × 1,150 × 550 mm or 600 × 600 × 600 mm. Compact parts run on 500 × 500 × 450 mm and 500 × 310 × 200 mm platforms. If your part is longer than the envelope, no amount of skill fixes it.

Ask two questions before you send a PO. Which machine will run this part, and how many setups? If the answer is three setups on a 3-axis machine for a ±0.005 mm bore pattern, get a second opinion.

• 1
  5-axis for compound anglesOne setup, one datum, better feature-to-feature relation.
• 2
  Mill-turn for round-plus-flat partsAvoids a second op and re-chucking error on shafts with cross holes.
• 3
  3-axis is fine for platesFlat parts with through holes and pockets rarely need more.

Aluminium 6061-T6 and 7075 cut cleanly and hold tight tolerance. Stainless 304 and 316L work harden, so feeds and speeds need to be right or the tool rubs and the surface tears. Titanium TC4 (Ti-6Al-4V) and Inconel move the cost up sharply, mostly through tool wear and slower passes.

Finishing is where quotes drift apart. Anodizing adds 5–25 μm per surface depending on type. If a bore is toleranced at ±0.005 mm and you anodize after machining, the bore closes up. The fix is to machine oversize by the coating thickness, or mask the bore. Either way, it has to be planned before the first cut, not after.

Hardcoat anodizing and electroless nickel behave differently again. Hardcoat builds more per side and is brittle at sharp edges. Electroless nickel is more uniform on complex geometry, which matters for internal channels.

Powder coating and black oxide are mostly cosmetic or corrosion protection, with loose dimensional impact. Bead blasting and tumbling change surface texture but not size. Laser marking needs a minimum character height of 1.5 mm to stay legible after coating.

• 1
  Plan finish before machiningState coating thickness on the drawing so the machinist can offset.
• 2
  Mask precision boresCheaper than reaming after coating, and keeps the tolerance band.
• 3
  Match finish to functionRa 0.2–0.8 μm for sealing faces, Ra 1.6–3.2 μm for general surfaces.

A useful quote separates material, machine time, finishing, inspection and any tooling. A single lump-sum number tells you nothing about where the cost sits, so you cannot negotiate or redesign to save money.

Capacity claims deserve a number. Machine count, axis configuration and maximum part size are all checkable. We run 127 high-precision CNC machines across three wholly-owned plants in Dongguan and Singapore, including 16 simultaneous 5-axis centers, 16 mill-turn centers, 27 three-axis machines, 12 four-axis mills and a Ø400 mm rotary table. That mix decides which jobs fit.

Lead time follows capacity. A shop that can start production within 24 hours is usually holding open machine slots, which means it is not fully booked. One quoting a month out may be busier, or may be batching your job behind larger runs.

MOQ is the quiet signal. No minimum order quantity, from one prototype to 10,000+ parts, means the shop is set up for both prototype and production work. A high MOQ on a first article often means the shop would rather not run small jobs at all.

• 1
  Get the machine namedAxis count and model class tell you what tolerance is realistic.
• 2
  Separate finishing from machiningIt is the line most often padded.
• 3
  Check the MOQ policyIt reveals whether prototypes are welcome or a nuisance.

Certifications should match your industry, not just exist. ISO 9001:2015 covers general quality management and is the baseline. IATF 16949:2016 is what automotive and EV buyers screen for. ISO 13485:2016 applies to medical devices. ISO 27001:2022 covers information security, which matters when you upload proprietary CAD files.

Inspection is the part buyers under-specify. A claim of 100% inspection before shipment should come with a defined sequence: raw material check, in-process monitoring, final inspection. If the shop cannot describe what happens between the first cut and the last, the claim is marketing.

Reports on request is a reasonable policy, but ask which reports. Dimensional reports from CMM and laser scanning against the CAD model are the useful ones for tight-tolerance parts. Material certificates matter for aerospace and medical.

For anything under NDA, confirm how files are stored and who can open them. Uploads should be secure and confidential, with an NDA available on request before you send the model.

• 1
  Match certificate to industryIATF 16949 for auto, ISO 13485 for medical, ISO 27001 for file security.
• 2
  Define the inspection sequenceIncoming, in-process, final. Ask who signs it off.
• 3
  Request CMM reportsDimensional data against CAD, not a visual check.

Not every part belongs on a mill. Thin sheet with large flat areas is faster and cheaper on a laser or punch. Sheet metal fabrication handles 1–3 mm panels with bends and holes at a fraction of the cycle time.

Parts with internal cavities and no draft are a machining job. Parts with internal cavities and draft are a casting job. If you are running 5,000 units of a simple bracket, die casting or vacuum casting will beat machining on unit cost, though tooling lead time and upfront cost are higher.

Very large, very simple geometry can also swing the other way. A 3,000 mm frame with a few drilled holes may not need a 5-axis center at all. Putting it on the wrong machine raises the price without improving the part.

The honest test: does the part need tight tolerance, complex geometry or a small quantity? If yes to any, machining fits. If the answer is no to all three, get a quote from another process before you commit.

• 1
  Sheet parts go to fabricationLaser cutting plus bending beats milling on thin panels.
• 2
  High volume simple parts go to castingTooling cost pays back above a few thousand units.
• 3
  Machining wins on tolerance and low volumeThat is the combination it is built for.
