Application of Electrical Sparks Treatment in the Mold Industry

Electrical sparks treatment is a thermal erosion process. A power supply holds a small gap, usually 0.02–0.10 mm, between the tool electrode and the mold block. Dielectric fluid floods the gap. Voltage breaks down the fluid, a spark forms, and a few thousandths of a cubic millimeter of steel melts and vaporizes. The fluid carries the debris away before the next pulse fires.

Because the electrode never touches the workpiece, hardness does not limit the cut. A 60 HRC hardened core sparks as easily as an annealed block. That matters in mold shops, where cavities are often milled soft, heat treated, then finished by sparking after the shrink correction is known.

The same physics drives two machine families. A sinking machine burns a three-dimensional cavity from a shaped electrode. A wire machine feeds a thin brass or coated wire past a stationary block and cuts a two-dimensional profile. Both count as electrical sparks treatment, and most mold shops run both.

• 1
  DielectricDeionized water for wire, hydrocarbon oil for sinker.
• 2
  Pulse on-timeLonger on-time cuts faster but leaves a rougher surface.
• 3
  No cutting forceThin ribs and sharp internal corners survive without deflection.

Deep ribs, sharp internal corners, and textured pockets are the classic cases. A 3-axis mill with an Ø6 mm end mill leaves a corner radius of at least 3 mm. If the part drawing calls for a 0.5 mm corner, someone has to spark it. The electrode is machined in graphite or copper, dressed to the corner radius, and burned in with an undersize allowance for the spark gap.

Electrode material is a cost decision. Graphite machines fast and survives high currents, so it suits roughing burns in large cores. Copper holds finer detail and leaves a better surface, so it is common on finishing electrodes and small features. Copper-tungsten appears when the electrode itself must survive thousands of discharges without wear.

Orbiting changes the planning. Instead of cutting the full cavity with one electrode, the machine moves a smaller electrode along a programmed path. This flushes debris better, allows one electrode to cover several sizes, and lets the operator dial in the final dimension by adjusting the orbit radius.

Wire sparking cuts through hardened steel with no electrode to make. That makes it the default for parting lines, ejector pin holes, and the outside profile of an insert that was hardened before finishing. Start holes are drilled first, then the wire threads through and follows the profile.

Multi-pass cutting controls the finish. A typical sequence runs one rough pass at high current, then three or four trim passes at decreasing energy. The final pass sets the surface and the size. Holding ±0.005 mm on a hardened insert is routine when the machine is thermally stable and the wire tension is right.

Taper cutting is the reason many mold shops keep a wire machine busy. A few degrees of taper lets one setup cut the draft angle on a core wall and the straight section below it. The limit is the machine head geometry, not the process, so check the taper angle against the machine specification before promising a feature.

Sparking is slow. A cubic centimeter of removed steel can take many times longer than milling. If a cavity is open enough for a Ø10 mm cutter, mill it. Save the electrode for the corners and the details the cutter leaves behind.

The recast layer is the other caution. Every spark leaves a thin remelted skin on the surface. It is harder and more brittle than the parent steel, and it can crack under thermal cycling in a production mold. Fine trim passes keep the layer thin, and stress relief or a light polish removes it where fatigue matters.

Electrode cost adds up on complex cavities. A deep rib with a shrinking cross-section may need three or four electrodes, each machined and dressed on a separate setup. On short-run tooling, redesigning the corner radius to suit a standard cutter is often the cheaper engineering decision.

Give the sparking cell the finished cavity dimensions, not the electrode dimensions. The machine operator works back through the spark gap and the orbit allowance. If the drawing only shows electrode size, the shop has to guess, and the first burn lands undersize.

State the surface finish on the mold surface, and say whether it is a visible surface or a hidden one. A Class A surface needs extra trim passes and often a hand polish afterward. A hidden rib that holds a clip only needs to be dimensionally correct.

Note the steel grade and its heat treatment state. Pre-hardened 1.2343 and through-hardened 1.2344 behave differently in the gap, and the pulse settings differ. If we are milling the electrode and the mold block together, the same note reaches both departments.

• 1
  Finished cavity drawingNot the electrode drawing, unless you also send the gap.
• 2
  Surface requirementVisible or hidden, and the Ra target if it matters.
• 3
  Steel and hardnessGrade plus condition, so pulse settings can be set.
• 4
  Corner radiiCall out radii under R 1 mm so they are not missed.

We run sinking and wire sparking alongside 127 high-precision CNC machines across 3 wholly-owned plants, covering 7,600 m² and 150 technicians. Mold inserts and cores that need both milling and sparking move through one production plan, so the electrode geometry is cut on the same tolerance budget as the cavity.

Our general machining tolerance is ±0.005 mm (±0.0002 in). As-machined surfaces sit at Ra 1.6–3.2 μm; fine trim passes reach Ra 0.2–0.8 μm. Hardened inserts are cut after heat treatment, which removes the distortion risk that comes from sparking a soft block and then hardening it.

Every part is inspected before shipment, with raw material checks, in-process monitoring, and a final report on request. We hold ISO 9001:2015, IATF 16949:2016, ISO 13485:2016 and ISO 27001:2022, and the tooling files sit inside that same documented flow.
