Aluminum cuts fast. A 6061-T6 block on a 5-axis machine can run at 12,000–18,000 rpm with a three-flute carbide end mill and still hold a Ra 0.8–1.6 μm finish on a wall. The metal is soft, the chip is light, and the cutting forces are roughly a third of what the same geometry would need in steel. That is why a shop doing aluminum CNC machining Lancashire work can push feed rates and keep cycle times short.

The catch is heat. Aluminum conducts heat away from the cut so well that the tool tip stays cooler than in steel, but the part itself expands. A 200 mm aluminum plate can grow 0.05 mm or more from a 10 °C rise in shop temperature. Machines running ±0.005 mm work measure the part, not the machine, and they let the stock sit before the finishing pass. If a supplier skips that step, the drawing tolerance will not hold on a hot afternoon.

Built-up edge is the other common failure. At low cutting speeds, aluminum smears onto the tool edge and the surface turns rough. The fix is simple: higher surface speed, sharper geometry, and a coolant or air blast that clears chips from the pocket. Shops that run aluminum all day set their tools for it. A general machine shop that runs steel and aluminum on the same schedule will often miss this and blame the alloy.

• 1
  Spindle speed6061 and 6082 cut clean at 12,000–18,000 rpm with carbide.
• 2
  Thermal driftA 200 mm plate grows about 0.05 mm per 10 °C rise.
• 3
  Built-up edgeLow speed plus soft alloy equals smeared flutes and poor Ra.
• 4
  Chip clearanceDeep pockets need through-spindle coolant or strong air blast.

Most aluminum parts fail on setup, not on the cutting tool. A thin wall or a tall rib will deflect when a vise closes on it, and no amount of toolpath tuning will bring it back. The usual answer is to hold the part on a sacrificial plate, use soft jaws machined to the profile, or leave tabs that get cut off at the end. For a part with a 1 mm wall, we often rough to 1.5 mm, let it relax, then finish to size in a second operation.

Five-axis work changes what is possible. A Ø400 mm rotary table with a 4,000 mm maximum processing size lets us cut angled faces, deep pockets and undercut features in one setup. That matters for aluminum because every re-clamp is a chance to lose 0.02 mm. On a complex aerospace rib or an EV motor housing, one setup can hold true position across a dozen faces that would otherwise need three or four fixtures.

There are limits. Deep, narrow pockets are hard to clear, and a tool that is long enough to reach the floor will chatter before it finishes. A 6 mm cutter at 5× diameter depth is comfortable; at 10× diameter, expect to slow down and take lighter passes. Sharp internal corners also need a smaller tool, which means more time. If a drawing calls for a 1 mm internal radius in a 40 mm deep pocket, the cost will jump and the shop should say so before cutting.

• 1
  Soft jawsMachined to the part profile to spread clamping load.
• 2
  Two-stage roughingLeave 0.5 mm, let the part relax, then finish.
• 3
  Tool reachKeep depth under 5× diameter where the geometry allows.
• 4
  Corner radiusA 1 mm internal corner in a deep pocket drives cost up fast.

Anodizing is not a paint. Clear and color anodize grow the part by roughly half the coating thickness per surface, typically 5–15 μm. A hardcoat can add 25–50 μm and it builds on edges faster than on flat faces. If a bore needs to stay at Ø10.000 mm after anodizing, the machined bore must be undersize by the growth. We ask for the finish callout before we set the tool offsets, not after.

As-machined aluminum sits around Ra 1.6–3.2 μm. A fine finish at Ra 0.2–0.8 μm is possible, but it needs a separate finishing pass, sharp tooling and sometimes a bead blast or polish afterward. Bead blasting hides tool marks and gives a matte look, but it rounds sharp edges slightly. Laser marking needs a minimum character height of 1.5 mm to stay legible after anodize.

Plating and powder coating add their own thickness. Electroless nickel goes on evenly and is a good choice for wear surfaces on aluminum, but it needs a zincate pre-treatment or adhesion will fail. Powder coating is thicker and softer, so it is usually kept off sealing faces and threaded holes. The engineering point is simple: decide the finish before the first cut, because the finish is part of the dimension.

• 1
  Anodize growthPlan 5–15 μm per surface for clear or color anodize.
• 2
  Hardcoat25–50 μm, thicker on edges; adjust bores accordingly.
• 3
  Bead blastHides tool marks but slightly rounds sharp edges.
• 4
  Laser markingMinimum character height 1.5 mm to stay readable.
